Carte mère NC9KDL Agrandir l'image

Carte mère NC9KDL

CMJEJNC9KDL-2700

Jetway

Mini ITX, INTEL ATOM D2700 Fanless , INTEL NM10 Chipset
2*DDRIII 1066, 2xGBE Lan, USB, VGA, LVDS, HDMI, 2X SATAII

Plus de détails

Carte Mini-itx Fanless dual GigaLan avec Atom D2700

- Next-Generation Intel Cedar Trail-D Platform
- Intel Atom D2700 Processor, 2.13GHz, Dual-Core, 32nm, 10W
- Intel NM10 Express Chipset
- Integrated PowerVR SGX 545 Graphics,640MHz
- Supports 1080P HD Playback, Blu-ray 2.0, DirectX 9
- Supports Dual Independent Displays
- Supports 2 * DDR3-800/1066 SO-DIMM up to 4GB
- Supports 2 * SATA2 3Gb/s Devices, HD Audio
- Dual Gigabit LAN with Enhanced Surge Protection
- HDMI/VGA and 24-bit LVDS Video Outputs
- Watchdog Timer System Reset, 1-255 min/sec
- Mini-ITX Form Factor (170mm x 170mm)

CPUIntel Atom D2700 Processor, 2.13GHz, Dual-Core, 32nm, 10W
Hyper-Threading Support
ChipsetIntel NM10 Express Chipset
VideoIntegrated PowerVR SGX 545 Graphics, 640MHz
Memory2 * 204-pin DDR3-800/1066 Single Channel SO-DIMM up to 4GB
Expansion Slots1 * PCI Slot
Storage2 * SATA2 3Gb/s Connectors
AudioVIA VT1705 5.1 Channel HD Audio
Network2 * Realtek RTL8111EVL PCI-E Gigabit LAN with Enhanced Surge Protection
LVDS1 * 24-bit Single Channel LVDS & Inverter Headers
USB8 * USB 2.0 Ports Total
Other FeaturesSupport ACPI S3, CPU Smart FAN, Watchdog Timer 1-255 min/sec
Rear Panel I/O4 * USB 2.0 Ports
1 * PS/2 Mouse Port
1 * PS/2 Keyboard Port
2 * RJ-45 Ports
3 * Audio Ports ( Line-in, MIC, Line-out )
1 * VGA Port
1 * HDMI Port
Internal I/O2 * USB Headers for 4 * USB 2.0 Ports
2 * Fan Headers
1 * 24-pin ATX Power Connector
1 * LVDS & Inverter Headers
1 * Audio Header
1 * Serial Header (RS232)
1 * Parallel Header
Front Panel Headers
BIOSAMI 16MB DIP Flash ROM
ComplianceCE, FCC, RoHS, ErP
TemperatureOperating Temp 0~40º C
Storage Temp -20-85º C
Form FactorMini-ITX Form Factor (170mm x 170mm)
